Size : 1 13/16” upto 30”
Pressure Rating : API 3000 PSI to 20000 PSI
Materials : All Material Classes as per API 6A and also Special Materials with Overlay.
Design Standard : API 6A
Pressure / Temperature Rating : API 6A
Test (Inspection) Standard : API 6A
Construction Details : Bolted Bonnet / Pressure Seal Bonnet, Non Rising Stem
End Connection : Flanged, Hub End, Butt-Weld
Operator / Actuator : Lever, Gear, Actuator (Pneumatic, Hydraulic, Electro-Hydraulic and Electric Motorised)
Special Design Feature also available :
• Extremely High Temperature
• Cryogenic Design
• Subsea Design
